Publisher: © "Monolith"
ISBN: 978-617-537-183-1-1
Number of pages: 41
Format: file PDF
About the manual
Type: ABD / AEX / APQ / ABU / AEA / AEE / AEK / AFT / AKS / AAM / ABS / ACC / ADD / ADZ / 2E / ABA / ABF / ACX / ADY / AEP / AGG / AKR
Displacement: 1.4 / 1.6 / 1.8 / 2.0 / 2.8 / 2.9 / 1.9D L.
Power: 64 / 75 / 90 / 172 / 190 hp
In the manual you will find
-
electrical wiring diagram for Volkswagen Golf 3 / Volkswagen Vento
-
electrical equipment Volkswagen Golf 3 / Volkswagen Vento
In this book, only the schemes of electrical connections are given.
To get acquainted and to buy the full book on car repair Volkswagen Golf 3 / Volkswagen Vento since 1991 (including electrics) it is possible under the
link
Content
Electrical equipment
Ignition system
Charging system
Starting system
Windscreen wipers and washers
Lighting and signaling
Appendix to chapter
Wiring diagrams
Using Schemes
Automatic transmission
Mono-Motronic control unit, ignition system, fuel pump (1.8L engines)
Mono-Motronic control unit, lambda probe (1.8 l engines)
Simos control unit, intake manifold, coolant temperature sensor, injectors, lambda probe (2.0 l engines)
Mono-Motronic control unit, injectors (1.8 l engines)
Simos control unit, ignition system, knock sensor, engine speed sensor (2.0L engines)
Simos control unit, air mass sensor, carbon filter solenoid, throttle module (2.0L engines)
Radiator fan, fresh air duct (1.8L engines)
Mono-Motronic control unit, intake manifold, throttle valve (1.8L engines)
Alternator, starter, fuel pump (2.8L and 2.9L engines)
Alternator, battery, starter, ignition switch (1.8L engines)
Oil Pressure Sensor, Speedometer (2.0L engines)
Oil pressure sensor, instrument panel, warning lights (1.8L engines)
Oil pressure sensor, speedometer, oil temperature sensor, coolant shortage sensor (2.8L and 2.9L engines)
Oil pressure gauge, speedometer (1.4L and 1.6L Maker)
Ignition control unit (1.4L and 1.6L engine)
Brake fluid level sensor, radio connections, cigarette lighter (1.8L engines)
Ignition control unit, injectors, throttle valve (1.4L and 1.6L engine)
Ignition control unit, knock sensors, air temperature, coolant (1.4 l and 1.6 l engine)
Motronic control module. engine speed sensor, carbon filter solenoid, coolant circulation pump (2.8L and 2.9L engines)
Motronic control module. knock sensor, throttle, air supply (2.8L and 2.9L engines)
Motronic control module, ignition system, lambda probe (engines of 2.8 l and 2.9 l)
Motronic control module, coolant, throttle control unit (2.8L and 2.9L engines)
Interior lighting, license plate light (1.8L engines)
Motronic control module, injectors (2.8L and 2.9L engines)
Dashboard, function display, oil gauge (1.8L engines)
Dashboard, fuel gauge, coolant gauge, warning lights (1.8L engines)
Heated driver's seat
Heated rear window, heated mirrors, license plate lights
Airbags
Heated passenger seat
Headlamp position (1.8L engines)
Airbags (with side airbags)
Turn signal, running lights
Turn signal, emergency signal
Warning lights, instrument cluster (2.8L and 2.9L engines)
Turn signal, running lights (1.8L engines)
Ignition system (1.4L and 1.6L engine)
Signal lamps, instrument panel, fuel gauge (2.8L and 2.9L engines)
Rear window wipers and washers
Windshield wipers and washers
Reversing lights, heated rear window (1.8L engines)
Headlights
